Description
The Zenith™ Series by Basic American is the Premier Extended Care Bed. Engineered for durability and function, the Zenith features sealed ball bearings in the joints for smooth, quiet movement and SilverSolutions in the powder coating to provide antimicrobial surface protection. Basic American by Graham-Field is a leading manufacturer of beds serving the senior living industry for 40+ years. We proudly manufacture our beds in the USA, in Fond du Lac, Wisconsin, which enables faster response to customers’ needs. Innovation with industry-leading technology is designed into the Basic American Zenith, Matrix, and Liberty models to provide feature-rich beds and value for every budget.
Features & Advantages
Made in the USA
- Minimal lead times
- Quality craftsmanship and manufacturing
SilverSolutions
- Located in the powder-coating which provides antimicrobial surface protection
- Premium Products
Sealed Ball Bearings
- Allows seamless, continuous, and noiseless movement
- Maintenance Free
SLIDE-W-I-D-E® Integrated Expandable Deck
- Slides located on the frame effortlessly slide in and out allowing for quick and easy transition
- Expandable/retractable deck adjusts to 36”‡, 39”, and 42” with two quick-release ball-detent pins on each side
ANSI/AAMI ES60601 Safety Certification
- Tip stability testing
- Load capacity testing (twice the operating capacity)
- Roll clearance testing
- Splash proof electronics testing
Optional ‘Plug and Play’ digital electronics enable future feature additions
- Staff Control for Trendelenburg and Reverse Trendelenburg
- Chair Position
- Underbed Light
- USB Charger
Certified as a transport device for the CMS Emergency Preparedness Plan
- Easy maneuvering/adjustability through doorways and hallways during emergency or evacuation
Intuitive two-pedal locking system
- Centrally located
- Easily visible and accessible at ALL heights and widths
Industry-leading, energy-saving electronics
- Reduces Energy Consumption
Grounded bed with right-angle hospital grade plug
- Provides added safety for both staff and residents
US Patented design of high/low mechanism
- Housed with the mainframe tubes; no holes are located on the top side that will harbor bacteria
Grid sleep surface with cross braces
- Sturdy, no-sag sleeping surface
Specifications:
- Adjustable Surface Length: maximum 84 inch
- Adjustable Surface Length: minimum 80 inch
- Fixed Sleep Deck Width: 36‡ inch
- Slide-W-I-D-E ® option Sleep Deck Widths: 36‡ or 39 or 42 inch
- Height Travel Range: maximum 30 inch
- Height Travel Range: minimum 7.95 inch
- Safe Work Load: (includes resident, support surface, head/footboards, and accessories) 550 lb
- Maximum Patient Weight: evenly distributed 500 lb
- Actuators: 4 dc
Warranty:
- Main Frame & Welds: 15 years
- Control Box & Actuator Motors: 5 years
- Hand Control Pendant & Cabling: 3 years
- Staff Control & Cabling: 3 years
- Head & Footboards: 1 year
- All Other Durable Components not otherwise listed: 1 year
